Premier Manufacturer of Agitator, Mixer & Reactor Seals in India

Sealventures is a distinguished manufacturer, supplier, and global exporter

specializing in high-performance Agitator, Mixer & Reactor Seals. Based in Mumbai, India, we engineer both Balanced and Unbalanced designs specifically optimized for pumps, compressors, and rotating equipment.

Our precision-engineered seals serve as direct, high-quality equivalents to industry-standard brands such as John Crane, Burgmann, Flowserve, AES, Chesterton, Vulcan, and Roten, ensuring seamless integration and reliability.

Engineering Excellence & Technical Specifications

At Sealventures, we leverage advanced manufacturing technologies and rigorous quality control to produce pusher seals that withstand demanding industrial environments.

Value-Driven Solutions and Global Logistics

We are committed to providing cost-effective sealing solutions without compromising on material integrity. Our streamlined production and logistics framework ensure:

Comprehensive Product Portfolio

As a leading Mumbai-based authority in sealing technology, Sealventures provides a comprehensive range of mechanical seals and support systems tailored to diverse industrial needs.

Our extensive portfolio includes Conical Spring Seals, Single and Multi Spring Seals, Wave Spring Seals, Rubber and PTFE Bellow Seals, Cartridge Seals, Metal Bellow Seals, Agitator and Reactor Seals, Dry Running Seals, and Split Seals. Beyond our standard and custom-engineered seals, we offer essential support hardware—including Thermosyphon Systems and Bearing Isolators—to ensure maximum operational reliability.

SV-AG125
SV-AG125

DRY RUNNING MECHANICAL SEAL

Materials

Seal Ring Faces :Spl. Carbon
Seat Faces :SiC
Elastomer :Viton, TTV, FEP and FFKM
Metal Parts :SS 304, SS 316, Hast-C, Alloy-20 & etc.

Operating Range

Shaft Dia: 20mm to 150mm
Pressure: Full Vacuum Up to 8 bar
Temperature: -30°C to 140°C
Speed: Up to 900 RPM

Features

  • Single seal
  • Balanced
  • Outboard mounted
  • Independent of direction of rotation.
ENQUIRY NOW DOWNLOAD
SV-AG225

AGITATOR MECHANICAL SEAL

Materials

Seal Ring Faces :Carbon and SiC
Seat Faces : SiC and TC
Elastomer : Viton, TTV, FEP and FFKM
Metal Parts : SS 304, SS 316, Hast-C, Alloy-20 & etc.

Operating Range

Shaft Dia: 20mm to 150mm
Pressure: Full Vacuum Up to 8 bar
Temperature: -30°C to 150°C
Speed: Up to 300 RPM

Features

  • Single seal
  • Cartridge unit
  • Independent of direction of rotation
ENQUIRY NOW DOWNLOAD
SV-AG225
SV-AG325
SV-AG325

DOUBLE AGITATOR MECHANICAL SEAL

Materials

Seal Ring Faces :Carbon and SiC
Seat Faces :SiC and Ceramic
Elastomer :Viton, PTFE, FEP and FFKM
Metal Parts : SS 304, SS 316, Hast-C, Alloy-20

Operating Range

Shaft Dia: 40mm to 200mm
Pressure: Up to 8 bar
Temperature: -25°C to 260°C
Speed: Up to 200 RPM

Features

  • Double seal
  • Balanced
  • Cartridge unit
  • Bearing arrangement
  • Heat trap arrangement (Optional)
  • Independent of direction of rotation
ENQUIRY NOW DOWNLOAD
