Premier Manufacturer of Pusher Seal in India

Sealventures is a distinguished manufacturer, supplier, and global exporter

Specializing in high-performance Pusher Seals. Based in Mumbai, India, we engineer both Balanced and Unbalanced designs specifically optimized for pumps, compressors, and rotating equipment.

Our precision-engineered seals serve as direct, high-quality equivalents to industry-standard brands such as John Crane, Burgmann, Flowserve, AES, Chesterton, Vulcan, and Roten, ensuring seamless integration and reliability.

Engineering Excellence & Technical Specifications

At Sealventures, we leverage advanced manufacturing technologies and rigorous quality control to produce pusher seals that withstand demanding industrial environments.

Value-Driven Solutions and Global Logistics

We are committed to providing cost-effective sealing solutions without compromising on material integrity. Our streamlined production and logistics framework ensure:

Comprehensive Product Portfolio

As a leading Mumbai-based authority in sealing technology, Sealventures provides a comprehensive range of mechanical seals and support systems tailored to diverse industrial needs.

Our extensive portfolio includes Conical Spring Seals, Single and Multi Spring Seals, Wave Spring Seals, Rubber and PTFE Bellow Seals, Cartridge Seals, Metal Bellow Seals, Agitator and Reactor Seals, Dry Running Seals, Split Seals. Beyond our standard and custom-engineered seals, we offer essential support hardware—including Supply Systems and Bearing Isolators —to ensure maximum operational reliability.

SV-CN11 Seal
SV-CN11

Conical Spring Mechanical Seals

Materials

Seal Ring Faces : Carbon, SiC and TC
Seat Faces : NiR, Ceramic, SiC and TC
Secondary Seal : Viton, Neoprene, EPDM, NBR and Buna-N
Metal parts : SS 304, SS 316, Hast-C, Alloy-20 & etc.

Operating Range

Shaft Dia: 10mm to 100mm
Pressure: Up to 7 bar
Temperature: −20°C to +140°C
Speed: Up to 3000 RPM

Features

  • For plain or stepped shafts
  • Single seal
  • Unbalanced design
  • Conical spring that rotates
  • Performance is dependent on rotation direction
ENQUIRY NOW DOWNLOAD
SV-S21 / SV-S21V

Single Spring Mechanical Seal

Materials

Seal Ring Faces: Carbon, SiC and TC
Seat Faces: Ceramic, SiC and TC
Secondary Seal: Viton, PTFE, GFT, TTV, EPDM, NBR, Buna-N
Metal parts: SS 304, SS 316, Hast-C, Alloy-20 & etc.

Operating Range

Shaft Dia: 10mm to 100mm
Pressure: Up to 10 bar
Temperature: −20°C to +150°C
Speed: Up to 3000 RPM

Features

  • For plain or stepped shafts
  • Single seal
  • Unbalanced configuration
  • Helical coil spring design
  • Rotation independent functionality
ENQUIRY NOW DOWNLOAD
SV-S21 Seal
SV-MS31 / SV-MS31W
SV-MS31 / SV-MS31W

MULTI SPRING MECHANICAL SEAL

Materials

Seal Ring Faces : Cabon, SiC and TC
Seat Faces : Ceramic, SiC and TC
Secondary Seal : Viton, PTFE, GFT, EPDM, NBR, Buna-N and FFKM
Metal parts : SS 304, SS 316, Hast-C, Alloy-20 & etc.

Operating Range

Shaft Dia: 10mm to 100mm
Pressure: Up to 10 bar
Temperature: -20°C to 260°C (Depending upon Elastomer)
Speed: Up to 3000 RPM

Features

  • For plain or stepped shafts
  • Single seal
  • Unbalanced design
  • Multi-spring retainer
  • Independent of the direction of rotation
ENQUIRY NOW DOWNLOAD
SV-SV-DMS31

MULTI SPRING DOUBLE MECHANICAL SEAL

Materials

Seal Ring Faces: Carbon, SiC and TC
Seat Faces: Ceramic, SiC and TC
Secondary Seal: Viton, PTFE, GFT, EPDM, NBR, Buna-N and FFKM
Metal parts: SS 304, SS 316, Hast-C, Alloy-20 & etc.

Operating Range

Shaft Dia: 10mm to 100mm
Pressure: Up to 10 bar
Temperature: -20°C to 260°C (Depending upon Elastomer)
Speed: Up to 3000 RPM

Features

  • For plain or stepped shafts
  • Double seal
  • Unbalanced
  • Multi-spring retainer
  • Independent of rotation direction
ENQUIRY NOW DOWNLOAD
SV-DMS31
SV-MS31DT
SV-MS31DT

MULTI SPRING DURA TYPE SEAL

Materials

Seal Ring Faces : Carbon, SiC and TC
Seat Faces : Ceramic, SiC and TC
Secondary Seal : Viton, PTFE, GFT, TTV, EPDM, NBR, Buna-N
Metal parts : SS 304, SS 316, Hast-C, Alloy-20 & etc.

Operating Range

Shaft Dia: 10mm to 100mm
Pressure: Up to 10 bar
Temperature: −20°C to 250°C
Speed: Up to 3000 RPM

Features

  • For plain or stepped shafts
  • Single seal
  • Unbalanced design
  • Open rotary multi-spring retainer
  • Independent of rotation direction
ENQUIRY NOW DOWNLOAD
SV-WS41

WAVE SPRING MECHANICAL SEAL

Materials

Seal Ring Faces: Carbon, SiC and TC
Seat Faces: Ceramic, Carbon, SiC and TC
Secondary Seal: Viton, PTFE, GFT, TTV, EPDM, NBR, Buna-N
Metal parts: SS 304, SS 316, Hast-C, Alloy-20 & etc.

Operating Range

Shaft Dia: 10mm to 100mm
Pressure: Up to 25 bar
Temperature: −40°C to +220°C
Speed: Up to 3000 RPM

Features

  • For both plain and stepped shafts
  • Single seal
  • Unbalanced Design
  • Independent of the direction of rotation
ENQUIRY NOW DOWNLOAD
SV-WS41
