Premier Manufacturer of Cartridge Seal in India

Sealventures is a distinguished manufacturer, supplier, and global exporter

specializing in high-performance Cartridge Seal. Based in Mumbai, India, we engineer both Balanced and Unbalanced designs specifically optimized for pumps, compressors, and rotating equipment.

Our precision-engineered seals serve as direct, high-quality equivalents to industry-standard brands such as John Crane, Burgmann, Flowserve, AES, Chesterton, Vulcan, and Roten, ensuring seamless integration and reliability.

Engineering Excellence & Technical Specifications

At Sealventures, we leverage advanced manufacturing technologies and rigorous quality control to produce pusher seals that withstand demanding industrial environments.

Value-Driven Solutions and Global Logistics

We are committed to providing cost-effective sealing solutions without compromising on material integrity. Our streamlined production and logistics framework ensure:

Comprehensive Product Portfolio

As a leading Mumbai-based authority in sealing technology, Sealventures provides a comprehensive range of mechanical seals and support systems tailored to diverse industrial needs.

Our extensive portfolio includes Conical Spring Seals, Single and Multi Spring Seals, Wave Spring Seals, Rubber and PTFE Bellow Seals, Cartridge Seals, Metal Bellow Seals, Agitator and Reactor Seals, Dry Running Seals, and Split Seals. Beyond our standard and custom-engineered seals, we offer essential support hardware—including Thermosyphon Systems and Bearing Isolators—to ensure maximum operational reliability.

SV-CTMB61
SV-CTMB61

METAL BELLOW CARTRIDGE SEAL

Materials

Seal Ring Faces :Carbon, SiC and TCc
Seat Faces :TC and SiC
Elastomer :Flexible Graphite
Metal Parts :SS 316,HAST-C and Carpenter 42
Bellow MOC :AM350, Inconel®, Hastelloy® C-276

Operating Range

Shaft Dia: 19mm to 100mm
Pressure: Up to 25 bar
Temperature: -70°C to 350°C
Speed: Up to 3000 RPM

Features

  • For plain shafts
  • Single Acting
  • Dual directional
  • Inside mounted
  • Independent of direction of rotation.
ENQUIRY NOW DOWNLOAD
SV-CT101

SINGLE CARTRIDGE MECHANICAL SEAL

Materials

Seal Ring Faces : Carbon, SiC, TC
Seat Faces : Ceramic and SiC
Elastomer : Viton, PTFE, FEP and FFKM
End fitting MOC : SS 316,HAST-C and Carpenter 42
MOC :SS 304, SS 316, Hast-C, Alloy-20

Operating Range

Shaft Dia: 20mm to 100mm
Pressure: Up to 18 bar
Temperature: -25°C to 260°C
Speed: Up to 3000 RPM

Features

  • Single seal
  • Balanced
  • Cartridge unit
  • Independent of direction of rotation
ENQUIRY NOW DOWNLOAD
SV-CT101
SV-CTD201
SV-CTD201

DOUBLE CARTRIDGE MECHANICAL SEAL

Materials

Seal Ring Faces :Carbon, SiC and TCc
Seat Faces :TC and SiC
Elastomer : Viton, PTFE and FFKM
End fitting MOC : SS 316,HAST-C and Carpenter 42
MOC : SS 304, SS 316, Hast-C, Alloy-20

Operating Range

Shaft Dia: 20mm to 100mm
Pressure: Up to 15 bar
Temperature: -30°C to 260°C
Speed: Up to 3000 RPM

Features

  • Double seal
  • Balanced
  • Cartridge unit
  • Independent of direction of rotation
ENQUIRY NOW DOWNLOAD
SV-CTG301

GRUNDFOS PUMP CARTRIDGE SEAL

Materials

Seal Ring Faces : Carbon, SiC and TCc
Seat Faces : Ceramic and SiC
Elastomer : Viton, PTFE, FEP and FFKM
End fitting MOC : SS 316,HAST-C and Carpenter 42
MOC :SS 304, SS 316, Hast-C, Alloy-20

Operating Range

Shaft Dia: 12mm to 100mm
Pressure: Up to 18 bar
Temperature: -25°C to 260°C
Speed: Up to 3000 RPM

Features

  • Single seal
  • Balanced
  • Cartridge unit
  • Independent of direction of rotation
ENQUIRY NOW DOWNLOAD
SV-CTG301
