Split Seals

Home / Split Seals

Premier Manufacturer of Split Seal in India

Sealventures is a distinguished manufacturer, supplier, and global exporter

specializing in high-performance Split Seal. Based in Mumbai, India, we engineer both Balanced and Unbalanced designs specifically optimized for pumps, compressors, and rotating equipment.

Our precision-engineered seals serve as direct, high-quality equivalents to industry-standard brands such as John Crane, Burgmann, Flowserve, AES, Chesterton, Vulcan, and Roten, ensuring seamless integration and reliability.

Engineering Excellence & Technical Specifications

At Sealventures, we leverage advanced manufacturing technologies and rigorous quality control to produce split seals that withstand demanding industrial environments.

Value-Driven Solutions and Global Logistics

We are committed to providing cost-effective sealing solutions without compromising on material integrity. Our streamlined production and logistics framework ensure:

Comprehensive Product Portfolio

As a leading Mumbai-based authority in sealing technology, Sealventures provides a comprehensive range of mechanical seals and support systems tailored to diverse industrial needs.

Our extensive portfolio includes Conical Spring Seals, Single and Multi Spring Seals, Wave Spring Seals, Rubber and PTFE Bellow Seals, Cartridge Seals, Metal Bellow Seals, Agitator and Reactor Seals, Dry Running Seals, and Split Seals. Beyond our standard and custom-engineered seals, we offer essential support hardware—including Thermosyphon Systems and Bearing Isolators—to ensure maximum operational reliability.

SV-SPL501 Split Mechanical Seal
SV-SPL501

SPLIT MECHANICAL SEAL

Materials

Seal Ring Faces : Carbon, SiC, TC
Seat Faces : SiC and TC
Elastomer : Viton, FKM, FFKM, EPDM and NBR
Metal Parts : SS 304, SS 316, Hast-C, Alloy-20 & etc.

Operating Range

Shaft Dia: 50mm to 150mm
Pressure: Up to 10 bar
Temperature: −30°C to 150°C
Speed: Up to 2900 RPM

Features

  • Fully split design
  • Balanced
  • Semi cartridge unit
  • Single seal
  • Bi-directional rotation
ENQUIRY NOW DOWNLOAD
